Having made successful UAV test flights at home in the Peak District, we have relocated to Svalbard for a week to test the equipment in the most challenging possible conditions. We are flying in temperatures as low as -10 C, in gusty wind and after pulling the UAV to the field site in its flight case on a sled behind a snow scooter. It is taking off and landing on platforms of compacted snow.
Nevertheless, so far it has performed magnificently. There has been no damage even to the delicate props during transport, suggesting the flight case is sufficient, and the autopilot seems to be deftly dealing with the gusty wind. It interfaces quickly with the laptop and it is easy to load a preprogrammed flight, even in these very cold conditions. It was quite difficult to take of and land in ‘stabilize’ mode with the wind though.
A few modifications I’d still like to make include a new landing gear design. The three legs are OK for flat, hard ground, but for ice and snow I think it would be much better to have something with skids, or possibly a circular base, as this would protect it from landing with a leg in a cryoconite hole and prevent the camera touching the snow if the legs sink. Also, at the moment any problem with a single leg compromises the UAV’s ability to land, whereas a unit that joins to the UAV in more than one place would give more redundancy.
The battery life is also significantly reduced in these temperatures. That’s to be expected, but I’m wondering if there are more mods we can make to extend the flight time for surveying big areas in Greenland.
This performance gives me hope for a successful mapping mission in Greenland, where the UAV will be used to map the ice surface in much less demanding conditions than we are experiencing here, but will be worked on more ambitious missions (higher, further, more frequent). We are continuing to test the UAV protocol in the field for a few more days, but will now focus on our methodology for pairing UAV flights with ground sampling rather than flight tech and UAV control.
As a bonus, we were treated to some aurora on the way in…
